SS4Y-25-SF-x

4″ IronFlex Single Rail

4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail
4″ IronFlex Single Rail

These standard-length rails are ideal for building and equipment protection against standard 5,000 lb. capacity forklifts. All parts are modular and use the patented SlowStop® rebounding technology to eliminate concrete damage from post impacts and resists denting during rail impacts.

Low height is ideal for stopping pallets and counterweights and minimizes flex distance.

Set up in 4’, 6’, and 8’ lengths, sections can be mixed and matched to fit your required layout. Pipe can even be field cut for exact fits.



Specifications

  • Color
    RAL 1023 Yellow Pipe on RAL 9005 Black Pedestal
  • Diameter
    4” (3.5” ANSI Schedule 40)
  • Dimensions
    25” H
  • Impact Rating
    I9-7 Rail (20,000 joules), I9-5 Post (10,200 joules)
  • Temperature Rating
    -40°F - 150°F
  • Pipe Coating
    60μm Galvanized + 150 μm Polyester Outdoor Powder Coating
  • Cast-Iron Coating
    Environmentally Friendly Water-Based E-Coat + Polyester Outdoor Powder Coating
  • Set Screws
    M16
  • Anchor Screws
    5/8” x 5-1/2” Concrete
