SS6Y-36-SF-XX

6” IronFlex Single Rail

6” IronFlex Single Rail
6” IronFlex Single Rail
6” IronFlex Single Rail
6” IronFlex Single Rail
6” IronFlex Single Rail
6” IronFlex Single Rail
6” IronFlex Single Rail
6” IronFlex Single Rail

These standard-length rails are ideal for heavy duty building and equipment protection against standard 5,000 lb. capacity forklifts. All parts are modular and use the patented SlowStop® rebounding technology to eliminate concrete damage from post impacts and resists denting during rail impacts.

Low height is ideal for stopping pallets and counterweights and minimizes flex distance.

Set up in 4’, 6’, and 8’ lengths, sections can be mixed and matched to fit your required layout. Pipe can even be field cut for exact fits.

Specifications

  • Color
    RAL 1023 Traffic Yellow with RAL 9005 Black Connectors
  • Diameter
    6.63” (6” schedule 40 pipe)
  • Dimensions
    36” Tall
  • Impact Rating
    I20-7 Rail (44,400 joules) / I12-7 Post (26,700 joules)
  • Temperature Rating
    -40°F - 150°F
  • Pipe Coating
    60 μm Galvanized + 150 μm Polyester Outdoor Powder Coating
  • Cast-Iron Coating
    Environmentally Friendly Water-based E-Coat + Polyester Outdoor Powder Coating
  • Set Screws
    M16
  • Anchor Screws
    3/4” x 6” Concrete
